Accurate IC layout with DRC, LVS, and PEX verification for flawless fabrication.
Sudhal Nanoelectronics offers full-custom layout design services for analog, digital, and mixed-signal ICs. We focus on matching device characteristics and symmetry techniques for optimal performance. Our physical verification uses Mentor Calibre tools ensuring compliance with foundry rules. Supporting advanced nodes from 180nm to 5nm, we provide post-layout simulations and documentation to help you achieve first-pass silicon success efficiently.
Silicon-proven layouts
Foundry-certified compliance
Rapid turn-around time
Popular
Custom Layout Design
We offer precision-driven custom layout design services tailored to your chip architecture needs. Our expert team ensures optimal area utilization and adherence to DRC/LVS standards.
Expertise in Analog, RF, Digital ICs
PDK-compliant layouts from 180nm to 5nm
End-to-end support from schematic to tape-out
Popular
Physical Verification
Ensure design integrity with our advanced physical verification services. We conduct DRC, LVS, and ERC checks to catch errors early in the tape-out process.
Full-custom layout for analog, digital, RF ICs
Certified compliance with foundry PDKs
Rapid, accurate tape-out support
